Material Hoisting Base – 200 Series – Adhesive
- This 200-series base is used for retrofit construction applications.
- The standard height of the base is 15, 18, and 24 inches. It comes with the cast in embed.
- This base will be cast into a concrete slab in one piece.
- This base can be used with A100 and A200 davit arms with sockets for bottom rotation.
- For top rotation, use A401 and A600 gusseted davit arms, no socket is required.
- The minimum embedment for the cast in studs is limited to 6 3/8 inches.
- A minimum of 8 inches slab is required.
Download our Material Hoists Brochure here for more information.
See Product Size Variations below.
For further inquiry on this product, please contact us at 1800 461.0575
Description
Product Size Chart
Below is a chart of our standard sizes. More are available upon enquiry.
| Model No. | Reach | Height | Slab Thickness Min. | Add-Ins | Base Plate Size | Embedment Depth |
| FA-DB2-23107S1-15 | 6′-6″ | 15″ | 8″ | None | 12″ x 12″ | 6-5/8″ |
| FA-DB2-23107S1-18 | 6′-6″ | 18″ | 8″ | None | 12″ x 12″ | 6-5/8″ |
| FA-DB2-23107S1-24 | 6′-6″ | 24″ | 8″ | None | 12″ x 12″ | 6-5/8″ |
| FA-DB2-23127S1-15 | 6′-6″ | 15″ | 8″ | Winch Socket | 12″ x 12″ | 6-5/8″ |
| FA-DB2-23127S1-18 | 6′-6″ | 18″ | 8″ | Winch Socket | 12″ x 12″ | 6-5/8″ |
| FA-DB2-23127S1-24 | 6′-6″ | 24″ | 8″ | Winch Socket | 12″ x 12″ | 6-5/8″ |
